HOME > DUSTKING > DKD


SPECIFICATION
Model No. Process flow
(/min)
Filtering Area
()
Filtering Velocity
(m/min)
Static pressure
(mmAq)
Motor
Kw(Hp)
FILTER
of filter
INLET
DUCT()
Air Consumption
(/min)
Min.~Max.
DKD-2 10~20 8 1.0~2.0 150~250 2.2 (3) 2 150 52
DKD-4 20~40 16 1.0~2.0 200~300 2.2 (3) 4 195 104
DKD-6 25~50 24 1.0~2.0 200~300 3.7 (5) 6 195 156
DKD-12 50~100 48 1.0~2.0 200~350 5.5 (7.5) 12 350 312
