| Fume Collector |
 |
Fume is a solid material with its diameter of 1§or less, generated in process of physical or chemical reaction such as
combustion and sublimation, and its collecting facility is decided according to characteristics and structural form of gas.
The monomer fume, generated in process of pressing and injection, is effectively collected by diatom, a colloid material
that has excellent adsorbability and porosity. |
|
Our patented fume collector absorbs fumes by passing gas through the diatomite-coated filter bag of a dust collector |
|
The repetitive operation of mist removing, diatomite coating and collecting gives effective performance to investment
cost and maintenance cost. Our system is widely used for plastic compounding factory. |
|
| Features |
|
Simple structure and easy operation due to using a
general bag filter dust collector. |
|
Excellent fume eliminating performance for investment
cost. (Stylene monomer elimination rate: 95%) |
|
Relatively low monthly diatom consumption (monthly
consumption: capacity x 1.2kg) and easy maintenance
Diatom Consumption (kg/month): The above values in the
table can vary according to operational experience and
conditions of a site. |
|
|
| Applications |
| |
Plastic Compounding Factories: ABS, PS, PP, HDPE, LDPE, Etc. |
|
Hydrocarbon Monomer (SM, AN, BD, etc.) and adhesive
materials (vapor, oil mist, etc.) generating places. |
|
Asphalt and diesel fume generating places. |
|
|
| SPECIFICATION |
| Model |
Gas Rate
(§©/min) |
Body Press
Drop
(§®Aq) |
Width
(§®) |
Length
(§®) |
Height
(§®) |
Diatomite usage
(kg/¿ù) |
Collector Basic
Model |
| HSFC-5 |
50 |
60 |
1280 |
1280 |
3450 |
60 |
HSBF-15 x 2 |
| HSFC-10 |
100 |
60 |
1740 |
1740 |
3600 |
120 |
HSBF-10 x 2 |
| HSFC-15 |
150 |
60 |
1970 |
1970 |
4000 |
180 |
HSBF-15 x 2 |
| HSFC-20 |
200 |
80 |
2450 |
2450 |
4400 |
240 |
HSBF-20 x 2 |
| HSFC-25 |
250 |
80 |
2450 |
2900 |
4400 |
300 |
HSBF-25 x 2 |
| HSFC-30 |
300 |
80 |
2450 |
3200 |
4400 |
360 |
HSBF-30 x 2 |
| HSFC-35 |
350 |
80 |
2450 |
3900 |
4400 |
420 |
HSBF-35 x 2 |
| HSFC-40 |
400 |
100 |
2900 |
3600 |
4400 |
480 |
HSBF-40 x 2 |
| HSFC-45 |
450 |
100 |
2900 |
4300 |
4400 |
540 |
HSBF-45 x 2 |
| HSFC-50 |
500 |
100 |
2900 |
4800 |
4400 |
600 |
HSBF-50 x 2 |
|
|
|
 |
|
