| A/C Tower ? |
 |
A/C Tower uses ¡°activated carbon, having a large inner surface area with porous fine holes and high adsorption
performance¡°, to collect solutions, to eliminate odors and to purify gas in processes. |
|
Activated carbon shows excellent effect in adsorbing organic vapor, and most of organic gases regardless of density
and moisture containing ratio. |
|
Adsorption process can be divided into the adsorption process and the regeneration process, in which the adsorbed
material is separated and removed mostly with overheated water vapor (340¡É, 0.3 kg/§²G). |
|
Our model is a kind of the fixed bed absorber. For the continuous treatment of inflow gas, two of the AC Towers are
installed in parallel to adsorb dust and regenerate air by turn. |
|
| Features |
|
Simple Operation and Manipulation / Low Maintenance
Cost due to Reuse of Active Charcoal. |
|
Activated carbon, used as an adsorber, is effective in
adsorbing organic vapor, and separates and collects wide
range of solutions with low boiling points. |
|
Regeneration of active charcoal is simple when adsorbing
performance gets declined during operation. |
|
Due to the short time required for adsorption, the
installation space is not large considering treatment
capacity. |
|
Excellent Collecting Ratio for Organic Gas. (98%) |
|
|
| Adsorbable Gases |
|
VOC, Most of NOX and SOX. |
¡Ø
Non-Adsorbable Polluted Gases: H2S, SO2, CH3SH,
NO3, Some of Livestock Odors |
|
| Applications |
|
Chemical Plants, Paint Manufacturing Factories, Printing
Solutions, Plastic, Extracting Process, Fermentation
Process, Food Industry, Leather Factories, etc. |
|
|
| SPECIFICATION |
| Model |
Gas Rate
(§©/min) |
Body Press
Drop
(§®Aq) |
A/C VOL.
(§©) |
Body size |
| W (mm) |
L (mm) |
H (mm) |
| HSAT-10 |
100 |
90 |
2.5 |
2400 |
1900 |
1900 |
| HSAT-20 |
200 |
260 |
3.0 |
2400 |
3500 |
2400 |
| HSAT-30 |
300 |
190 |
3.5 |
2400 |
4000 |
2400 |
| HSAT-40 |
400 |
320 |
4.0 |
3000 |
2200 |
2400 |
| HSAT-50 |
500 |
360 |
4.5 |
3000 |
2700 |
2400 |
| HSAT-60 |
600 |
400 |
5.0 |
3000 |
3000 |
2400 |
| HSAT-70 |
700 |
420 |
5.5 |
3000 |
3000 |
2700 |
| HSAT-80 |
800 |
460 |
6.0 |
3000 |
3000 |
3000 |
| HSAT-90 |
900 |
500 |
6.5 |
3000 |
3000 |
3000 |
| HSAT-100 |
1000 |
540 |
7.0 |
3000 |
3000 |
3000 |
|
|
|
 |
|
